The carts are powered by lithium batteries that can cover between 80 and 100 kilometers of terrain with their maximum speed being in the range of 30 to 40 kilometers per hour with a 4 wheel hydraulic drum brake system.
Battery |
48V 150Ah Lithium Battery |
Overall Size |
about 3590*1260*1950mm |
Motor |
4KW AC Motor |
Max Load |
about 800 kgs |
Controller |
Enpower |
Net Weight |
about 750 kgs |
Charger |
48V 18A |
Chassis And Frame |
Steel |
Suspension |
Front double cross arm independent suspension/rear leaf spring suspension |
Wheel Base |
about 1720mm |
Steering |
Self Compensating" Rack & Pinion" Steering |
Tire Size |
23*10-12 |
Brake |
Rear wheel Mechanical Drum Brake &Mechanical parking |
Ground Clearance |
about 150mm |
Passenger Capacity |
6 Passengers |
Brake Distance |
about 5 m |
Driving Distance |
about 80 km |
Miniumum Turning Radius |
about 3.5 m |
Max Speed |
about 30 km/h |
Max Climbing |
about 20% |
